The diesel locomotive DR Class 130 (DB BR 230) belongs to the construction type Co'Co'. In the Co'Co' type, three individually driven axles are installed in two different frame bogies.

Continue reading
[addthis tool="addthis_inline_share_toolbox_upen"]

The diesel locomotive DR [amazon_textlink asin=’B00DTSHA6M’ text=’Class 130′ template=’ProductLink’ store=’eisenbfrbln-21′ marketplace=’DE’ link_id=’63968b8b-d3d7-11e8-a99b-9976f3a1249e’], also called “Ludmilla” or “Taigatrommel”, are machines that were manufactured from 1970 – 1982. The locomotives were produced by the Ukrainian company Lokomotivfabrik Voroshilovgrad (now Lugansk), which was once founded by the German merchants Gustav Hartmann and Richard Hartmann. The units were exported from the former Soviet Union to the GDR. The Deutsche Reichsbahn used the locomotives for passenger and freight transport, for example for the transport of lime and coal, as well as express train and D-train. A total of 873 locomotives in the German Democratic Republic were used as series 130, 131, 132, and 142. The diesel locomotives DR Class 130 come to a top speed of up to 140 km / h, with an hourly output between 2200-2940 kW. The pull-in force of the diesel locomotive class 230 is 294-450 kN. After the fall of the wall in 1989, the trains of the diesel locomotive BR 230 also drove to the west all the way to Kassel, Hamburg and Cologne and supplied West Germany with a wide variety of goods. With the merger of the German Reichsbahnen, the machines of the DR Class 130 diesel locomotive were used throughout Germany, thus making an important contribution to economic growth within the Federal Republic of Germany.

Details of the DR Class 130

  • Manufacturer: Locomotive factory Voroshilovgrad
  • Length: 20620 - 20820 mm
  • Numbering: Various
  • Weight: 122 - 124,7 t
  • Years of construction: 1970 - 1982
  • Top speed: 100 / 120 / 140 km/h
  • Retirement: few operational
  • Fuel supply: 6000 l Diesel
  • Attractive force: 294 - 450 kN
  • Numbers: 873
  • Power: 2200 - 2940 kW
  • Engine type: Kolomma 5 D 49 / 16 Tsch N 26/26
  • Train heating: elctric
  • Command: PZB, Sifa

Construction and remaining of the diesel locomotive DR Class 130

The locomotives consist of a steel frame, which is equipped with a mounted locomotive box in sheet metal profile construction, thereby creating sufficient space for additional equipment. The power transmission of the machines is done electrically. The series is powered by a direct-injection 16-cylinder four-stroke diesel engine, which comes with a turbocharger and intercooler to a power of 2200 kW (3000 hp). The machines were manufactured especially for the German market. Of the models, only a few could be exported, such as to Bulgaria, Czechoslovakia, and the USSR. Also in Bosnia-Herzegovina locomotives of the diesel locomotive DR Class 130 were used. Many of the trains have been rebuilt to work in different applications. Among other things, as an express train, the copies were used successfully and were able to transport people at top speeds.
